Order code: BNI0005
Order code: BNI0005
Function Input module Number of inputs 8 Configurable in-/outputs No Number of plug-in positions 8
General attributes
Approvals / Conformity CE Enclosure Type per IEC 60529 IP67 (when connected) Indicator IO-Link comm. Yes, LED green Indicator sensors supply US Yes Indicator switching function Yes Mounting instruction See short guide Product group Network interface Scope of delivery 12x labels
4x plugs M12
Short guideTransmission protocol IO-Link 1.0
Electrical attributes
Configurable in-/outputs No Current sum US (Sensor) 1.2 A Cycle time min. 3 ms Eff. operating voltage Ue DC 24 V Indicator modul supply Yes, LED green Inputs PNP, Type 2 Number of inputs 8 Operating voltage UB max. DC [V] 30.2 V Operating voltage UB min. DC [V] 18 V Process data cycle 3 ms at cycle time min. Transfer rate COM2 (38.4 kBaud)
Mechanical attributes
Ambient temperature Ta max. 55 °C Ambient temperature Ta min. -5 °C Connection sensors/actuators M12x1 Frametype 2.2 Height 31.0 mm Housing material Trogamid CX9704 Housing shield No Length 115.0 mm Mounting type 3-hole screw mounting Number of plug-in positions 8 Storage temperature max. 75 °C Storage temperature min. -25 °C Style Two-row Width 50.0 mm
