Mô-đun MAS-AI-08-D Masibus Viêt Nam
MAS-AI-08-D Masibus
Masibus Analog Input Field Interface Board has 8 channels that accepts various types of current/voltage signals and converts them to isolated current/voltage signals. It is compact universal DIN rail mounted with labeled input and output connections. Each channel zero and span calibration is adjustable by multi-turn potentiometers.
It is compatible with both 2 wire and 4 wire transmitters and has built-in transmitter power supply to power 2 Wire field transmitters.
Offers excellent accuracy and stability for reliable operation in hostile environments and offers full 3 port isolation between input, output and power supply.
Applications
Eliminate Ground Loop problems
Protect Expensive control systems against Field Faults
Isolate and Translate Field Signals
Eliminate Common Mode Voltages
Field Interface for PLC/DCS/SCADA systems
Features
Input | |
No of channels: | 8 No of Channels |
Input & Output Type: | DC Volt/Current (Factory Set) |
Input Indication: | Input over/under range Indication (1-5V/4-20mAonly) |
I/P Connection: | PCB Terminal Block accepts 2.5mm2 conductor size |
Output | |
Accuracy: | 0.1% of Span |
Output Terminals: | PCB Terminal Block or 25 pin D-Type connector |
Power Supply | |
Power Supply: | 24VDC ±10% |
Power Supply Protection: | By Fuse |
Power Supply Status Indication: | Healthy and Fault Indication |
Isolation | |
1.5KV AC Input to Power, Channel to Channel, Input to Output and Output to Power | |
Physical | |
Dimension (mm): | 225(L) x 90(W) x 90(D) |
Weight (gms): | Appx. 450 gms |
