iX T10A BeiJer Electronics
iX T10A BeiJer Electronics
10.4” graphic touch HMI with iX software
- 10.4″ TFT-LCD touch screen
- 640 × 480 (4:3)
- Application storage 80 MB
- Operating temperature -10 to +60 °C
- CE and UL508 approvals
Facts
General description
| Article number | 630000302 |
| Part status | Active |
Mechanical
| Mechanical size | 280 x 228 x 52.2 mm |
| Touch type | Resistive type |
| Weight | 1.5 kg |
| Housing material | Powder coated aluminum |
Power
| Input voltage | +24 VDC (18 – 32 VDC) |
| Power consumtion | 9.0 W |
| Input fuse | Internal DC fuse, 2.0 AT, 5 x 20mm |
Display
| Size diagonal | 10.4 inch |
| Resolution | 640 x 480 pixels |
| Backlight | LED backlight |
| Backlight life time | 50,000 hrs |
| Backlight brightness | 450 cd/m2 |
| Backlight dimming | Industrial |
| Display type | TFT LCD |
Communication serial
| Number of serial ports | 2 Port combined 9pin DSUB with dual pin out |
| Serial port 1 | RS 232 (RTS/CTS) |
| Serial port 2 | RS422/485 |
| Serial port 3 | RS 232 |
| Serial port 4 | RS422 (RTS)/RS485 |
Ethernet communication
| Number of ethernet ports | 1 |
| Ethernet port 1 | 1×10/100 Base-T (shielded RJ45) |
Environmental
| Operating temperature | -10 to + 60 °C |
| Storage temperature | -20 to + 70 °C |
| Shock | 10G 11ms half sine |
| Vibration | 0,7G RMS |
| Sealing front | IP65 |
| Sealing back | IP20 |
| Humidity | <85 % non-condensed |
Resources
Drawings
- CAB105 Cable Drawing for TxA / TxB / TxC iX operator panel
- CAB106 Cable Drawing for TxA / TxB / TxC iX operator panel
- CAB107 Cable Drawing for TxA / TxB iX operator panel
- CAB109 Cable Drawing for TxA / TxB / TxC iX operator panel
- CAB110 3m cable for iX TxA/ TxB and TxC
- iX Panel T10A 3D Drawing
- iX Panel T4A Outline Drawing/Panel Cut-Out
- iX Panel T7A 3D Drawing
- iX Panel T7A Outline Drawing/Panel Cut-Out
- CAB113: iX TxA/B/C to BFI ModBus RS485
- iX Panel T4A 3D Drawing
- CAB102 Cable Drawing for TxA / TxB / TxC iX operator panel
- CAB104 Cable Drawing for TxA / TxB / TxC iX operator panel
- CAB103 Cable Drawing for TxA / TxB iX operator panel
- CAB101 Cable Drawing for TxA / TxB / TxC iX operator panel
- CAB100 Cable Drawing for TxA / TxB / TxC iX operator panel
- iX Panel T10A Outline Drawing/Panel Cut-Out
Knowledge
- FX3U-ENET-ADP and iX T7A, Example
- iX – Data Exchange using Siemens, is swapping made by iX (QuickAnswer: Yes)
- iX – Fonts preinstalled in Panels operative
- iX – How to enter the Service Menu to set a new IP address, calibrate touch etc
- iX – How to enter update mode for system software upgrade
- iX – How to set the IP-address on a TxA/TxB panel.
- iX – Tutorial – How to setup a SIEMENS S7 ISO-on-TCP Controller in iX
- iX – TxA/TxB/TxC Modbus to Pluto safety PLC
- iX Panel TxA, TxB and TxC, batteries
- TxA / TxB – MAC-CAB adaptor for use with old cabling
- TxA / TxB connecting to an old A/AnS/AnU using the Melsec A-Series (CPU) driver
- iX Scripting – Win CE using System.Windows.Forms. MessageBox.Show() and the MessageBoxButton (QA: All 5 args has to be passed with method)
- TxA arabic and hebrew
- iX – How to change recipe layout (add/remove tags or change datatypes on tags) without loosing data
- iX – Printing from an iX Panel (over the network)
- iX – ValidationBuild error: Missing fonts, which are assigned to groups
- IX and animated GIF gives error on validation
- AXIS camera settings (for PRO+, iX Txxx and iX TxA panels)
- iX 2.0 OPC UA Server
- iX – Alphanumeric keyboard shows a few buttons only
- iX Web Server – FTP does not allow you to edit WebSite files online
- iX T7A, Com2 or com4 (RS-422) to FX-series?
- Instructions for battery recharging (TxA)
- iX – Transparent Mode Qnn serial through an iX panel with Serial/IP
- Overview – iX panel pixel density and aspect ratio
- iX – USB Recommended for downloading, system software upgrade, (QA:ordernumber 318272)
- iX – How to download application with USB
- TxA/TxB/TxC approximate boot time
- iX – Accessing files by FTP does not work, cannot open Logger-folder
- How to check what battery type your TxA is equipeed with
- TxA panel T4A, T7A, T10A batteries, do they need to be replaced?
- iX – T/TA/TxA/TxB SQL-Client is not avaliable
- Sketch – connecting a TxA/TxB/TxC to Mitsubishi A/Q C24 RS422 screw terminals.
Information document
- iX Panel TxA Maintenance Modes (PIEN282)
- Remote Access Web applet blocked by security settings after updating Java 7 to Update 51 or later
- iX TxA Environmental Impact Report _PDM_PROJ_DOC – 1015856 – 1 – A2_ – 1
- iX TxA USB memory compatibility
System program
- iX TxA image 1.0
- iX TxAx Image 1.11
- iX TxA Image 1.2
- iX TxA Image 1.1
Brochures
- Brochure: iX HMI solution & iX HMI software
Certificates
- DNV Certificate iX T4A , iX T7A, iX T10A , CiX-CAN
- DNV Certificate iX T7AM +CiX-CAN
- GL Certificate TxA (PROD CERT – 1025206 – 1 – A1) – 1
- iX Panel T4A Declaration of Conformity EMC
- iX Panel T7A Declaration of Conformity EMC
- iX T7AM BV Bureau Veritas Certificate 37193!A0 (PROD CERT – 1031965 – 1 – A1) – 1
- Loyd’s Register Type Approval Certificate T7AM (PROD CERT – 1029198 – 1 – A1) – 1
- T7AM RS certification 15090600 (PROD CERT – 1034990 – 1 – A1) – 1
- iX Panel T10A Declaration of Conformity EMC
- Green Passport iX TxA
- iX T7AM ABS PDA Certificate 14-HG1139922-PDA (PROD CERT – 1031909 – 1 – A1) – 1
- iX T7AM GL certification 60 108 – 13 HH (PROD CERT – 1031361 – 1 – A1) – 1
- UL Certificate iX TxA, TAx, EPC TAxAM
- Declaration of conformity iX Panel TxA
- Declaration of conformity EMC ciX-DP
Program examples/Quickstarts
- iX – TxA Demo
- Start-up document, Transparent mode with iX Developer 2.0 (KI00318 rev. A)
- Start-up document, QnUDE Ethernet – iX Panel (KI00313)
- Start-up: iX TxA/TxB – Programmable I/O (PIO) NA-9379 (KI00343)
- iX Developer Samples
- Start-up: IPsec VPN tunnel to iX panel (KI00333)
- iX Developer 2.10.1042 Program example for Modbus TCP communication between iX T7A and BFI-H2 or BFI-P2
- Startup Documents CiX-CAN FreeCAN
- IX terminals delete datalog export files from internal or usb memory
Manuals
- iX T4A Installation manuals
- TxA_Service_and_Maintenance_MAEN021_English
- iX T7AM Installation Manual
- iX T10A Installation manuals
- iX T7A Installation manuals
- ciX-DP Mounting instructions iX TxA and iX TxB
- Driver help file for ciX-DP MPI/Profibus DP module
Product information
- iX TxA rev2 PCN (PDM_CDOC – 1030566 – 1 – A2) – 1
- T4A new display and Touchscreen (PDM_CDOC – 1123673 – 1 – A1) – 1
- iX_EXTER_E1000_Environmental
Configuration files
- GSD files for ciX-DP Profibus module
